Explosion Proof Gas Cylinder Filling Equipment 1.6Mpa Earthquake Resistance
Product Details:
| Place of Origin: | China |
| Brand Name: | Xiangkang |
| Certification: | ATEX, CNEX, ISO9001 |
| Model Number: | S-TCS-YG-SV |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Standard Carton Pack, Each Set Packed in 4 CTNS |
| Delivery Time: | 5-8 work days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 1000000 Sets per month |
|
Detail Information |
|||
| Product Name: | Bottle Or House Cooking Camping BBQ Propane Gas Filling | Rated Power &Frequency: | 220V 50/60Hz |
|---|---|---|---|
| Division: | 50g | Available Industrial: | Energy And Mining,Industrial Gas,LPG Industry |
| Accuracy: | Class 3 | Pressure: | 0~1.6Mpa |
| Ex-proof Grade: | Ex Ib IICT4 Gb | Certificate: | ATEX,CNEX,ISO9001:2015 |
| Weighing Capacity: | 2Kg-180Kg | Package: | Standard Carton Box |
| Filling Speed: | High Speed With Safety | Special Function1: | With Computer Network Management System To Monitor The Gas Filling |
| Special Function2: | With Earthquake Resistance Features | ||
| High Light: | Explosion Proof Cylinder Filling Machine,Gas Cylinder Filling Equipment 1.6Mpa,CNEX Gas Cylinder Filling Equipment |
||
Product Description
XiangKang is a leader enterprise in LPG industry in China,we manufacture lpg filling machines and cylinder tag,LPG gas refilling plant,lpg skid sation,also software system.
Electronic power type lpg gas filling scales
We are a professional manufacturer for LPG filling scale,Cylinder tags,cylinder tracking,automatic gas filling scale,electric filling scale,intelligent filling machine,interlocking filling scale,Li-ion battery type filling scale,cooking gas filling,propane gas filling,bottled gas filling,explosive proof filling scale,liquefied petroleum gas filling machine,industrial gas filling,cylinder valves,lpg filling weighing scale,lpg filling weighing machine,Propane Fueling Stations,double nozzle filling scale,cylinder bar code tags,cylinder label,pet care tags,asset tracking bar code tags and etc.
|
Performance parameters |
|
| Module | S-TCS-YG-SV-180 |
| Accuracy | III |
| Min. & Max. weighing | 2KG-120KG |
| Certificates | CNEX, ATEX, ISO9001 |
| Div. | 50g |
| Operating pressure | 0~1.6Mpa |
| Suitable gas | LPG |
| Ex-proof | Ex ib IICT4 Gb |
| Power Supply | 220V |
| Rated Frequency | 50/60Hz |
Here are the process of filling bellow for clearer idea,very simple to operate according the steps:
1.Place the cylinder on the empty scale platform and scan the cylinder barcode(press the scan key, and the laser line will be aligned with barcode symbol)
2. Open the valve(pressure handle) and start filling
3.After filling, the data will be transmitted into software system. Automatically cut off of the arrivak quantity and wirelss transmission of data. Through the software, the daily filling data and files can be statistically summarized.
4. The software system updates in real time and uploads the filling data to the network platform.
We do module design for our liquid petroleum gas filling machine.It will be much easier for maintenance.
The modules for filling scales are:Soldenoid valve, power box, hanging barrel,tools, display, LPG pipes, cable pipes, support rod,scale platform, scanner and holder, seals
Our gas cylinder weighing scale have been well used of LPG refill,liquid chlorine refill,liquefied gas refill,CO2 gas filling,and other industrail gas refill,not only for home use cooking gas filling,also for BBQ cylinder gas filling,and some LPG gas plant.
- ATEX,CNEX,ISO9001:2015 certificate
- Electronic power type and battery type
- Different filling module,net filling,total filling,standard filling type
- Filling scale can be with different nozzles,double nozzles is available
- Electronic power type and battery type
- And etc.
