High Temperature-Resistance UID QR Barcode for LPG Cylinder Tracking

High Temperature-Resistance UID QR Barcode for LPG Cylinder Tracking

Product Details:

Place of Origin: Changzhou, China
Brand Name: Xiangkang
Certification: ISO9001, CNEX, ATEX
Model Number: LPG Cylinder Barcode

Payment & Shipping Terms:

Minimum Order Quantity: 100pcs
Price: Negotiable
Packaging Details: Standard Export Carton Pack
Payment Terms: L/C, T/T, Western Union
Supply Ability: 10000pcs per month
Get Best Price Contact Now

Detail Information

Product Name: Square Cylinder Barcode Color: White Base, Black Bar Code
Life Time: 20 Years Outdoor Temperature Resistance: -40℃ ~ 800℃
UV Resistance: Yes Chemical Resistance: Yes
Unbreakable: Little Bend Available Size: 35*53*1.2 Mm
Scan Speed: 1 Second Usage: Custom Sticker

Product Description

High Temperature-Resistance UID QR Barcode for LPG Cylinder Tracking

Product Description
Barcode system will help you the bellow supply chains:

Filling: your inventory becomes accurate and automated, cylinders are filled with the exact amount of gas, and tested automatically to detect any defect.
Distribution: Giving you complete visibility from dispatch to return, giving you the opportunity to map and monitor routes to increase efficiency.
Point of sale: The unique identification of each cylinder can be seen in real-time at each point of sale, and digitization helps removing paperwork and streamline processes.
End-user: The end user can access the LPG cylinder information by scanning via a smart mobile APP.

Permanent Metal-ceramic Composite Barcode for Tracking LPG Cylinders

One Cylinder with unique ID, Once Installation Permanent Use, Life Time at Least 20 Years

High Temperature-Resistance UID QR Barcode for LPG Cylinder Tracking 0



Characteristic
Item Barcode
High Temperature Resistance 800℃
Low Temperature Resistance -40℃
Chemical Corrosion Yes
Color White Base, Black Barcode
UV Resistance Yes
Scrap with An Art Knife Allowed Scraping 10 times without damage
Unbreakable Little bend is available
Life Time At Least 20 Years



Product Details Show



High Temperature-Resistance UID QR Barcode for LPG Cylinder Tracking 1

High Temperature-Resistance UID QR Barcode for LPG Cylinder Tracking 2

Main Functions

 High Temperature-Resistance UID QR Barcode for LPG Cylinder Tracking 3

High Temperature-Resistance UID QR Barcode for LPG Cylinder Tracking 4

Cylinder Information

 e.g. Display information on APP about cylinder information



High Temperature-Resistance UID QR Barcode for LPG Cylinder Tracking 5



Product Features
  • 1) Outstanding high temperature 800℃ resistance
  • 2) Low temperature resistance -40℃
  • 3) Scraping 10 times with an art knife without damage to the surface
  • 4) Resistance to chemical reagent corrosion, penetration of acetone for half an hour, wipe with wire ball for removal without damage
  • 5) White base, black barcode, easy to read
  • 6) Excellent image resistance to damaging UV exposure, 20 years practice proof
  • 7) Ceramic layer protects the image from chemical abrasion
  • 8) Unbreakable ceramic technology, little bit bend is available
Products Application

Applications for tracking LPG cylinders, and other industries

High Temperature-Resistance UID QR Barcode for LPG Cylinder Tracking 6

High Temperature-Resistance UID QR Barcode for LPG Cylinder Tracking 7

High Temperature-Resistance UID QR Barcode for LPG Cylinder Tracking 8

Barcode VS RFID

Comparison barcode between RFID

Material for cylinder tag is Ceramic-metal,It has some clear advantages over RFID.

High Temperature-Resistance UID QR Barcode for LPG Cylinder Tracking 9



Item
Permanent cylinder tag
RFID
Life time
20years
2-5years
High&Low temperature resistance
-40~800℃
-20~220℃
Reading speed
One by one
Batch read,but not stable
Cost
low
high
Reader
PDA or mobile phone
Special reader
Cylinder Renewal Process
No need take barcode away
Must take down and packing in sequence
Successful case
XiangKang,Trackabout,BOC,
Linde
None



Installation Barcode

Two methods:

  • For New Cylinder by Welding:

High Temperature-Resistance UID QR Barcode for LPG Cylinder Tracking 10

  • For old cylinder by drilling and riveting:

High Temperature-Resistance UID QR Barcode for LPG Cylinder Tracking 11

High Temperature-Resistance UID QR Barcode for LPG Cylinder Tracking 12

Explanation of the System

The hardwares demanded for the system:

  • 1 x computer with software(internet or net)
  • 1 x communication server
  • 1 x wirelss base
  • n x LPG filling scales



High Temperature-Resistance UID QR Barcode for LPG Cylinder Tracking 13
